02 / 09
KEY FEATURES
- Double-layer hydrophilic PES membrane
- Sterilizing-grade liquid filtration
- Low protein binding
- Integrated Stäubli vent
- High flow at low pressure drop
- Adhesive-free thermal construction
Puretratech · P-PT72KASTCS
Double-Layer Hydrophilic PES Sterilizing-Grade Capsule Filter — Sterile preparations and large-volume parenterals (LVPs) and Biologics and vaccine terminal filtration
Double-Layer Hydrophilic PES Sterilizing-Grade Capsule Filter for Sterile preparations and large-volume parenterals (LVPs) and Biologics and vaccine terminal filtration. Its construction, retention rating and operating limits are the same as the base model PT72KASTCS.
Application field: PSterilizing grade: Yes
Request a quote
View larger image01 / 10SKU / ModelP-PT72KASTCS
MOQ12 pcs
Lead time10 days
Country of originChina
HS code8421999090
Support / warranty3 years
01 / 09
PRODUCT OVERVIEW
Double-Layer Hydrophilic PES Sterilizing-Grade Capsule Filter for Sterile preparations and large-volume parenterals (LVPs) and Biologics and vaccine terminal filtration. Its construction, retention rating and operating limits are the same as the base model PT72KASTCS.
If you are considering this product for Sterile preparations and large-volume parenterals (LVPs) and Biologics and vaccine terminal filtration, confirm process-fluid compatibility, retention rating, operating conditions and any sterilization or sanitization requirements before ordering.
The double-layer hydrophilic PES membrane provides a redundant retention barrier for critical aqueous biopharmaceutical filtration while limiting protein adsorption.
The thermally bonded polypropylene capsule includes a Stäubli vent for online integrity testing and delivers high flow with low extractables.
03 / 09
APPLICATIONS
- Sterile preparations and large-volume parenterals (LVPs)
- Biologics and vaccine terminal filtration
04 / 09
MATERIALS
| Component | Material / method |
|---|---|
| Filter membrane | Double-layer polyethersulfone (PES) |
| Media support | Polypropylene (PP) |
| End caps | Polypropylene (PP) |
| Inner core | Polypropylene (PP) |
| Outer cage | Polypropylene (PP) |
05 / 09
BIOLOGICAL SAFETY
All components meet the biological-safety requirements of USP Class VI for plastics at 121 °C.
06 / 09
FOOD SAFETY COMPLIANCE
Materials of construction comply with applicable FDA regulations for food and beverage contact use, as detailed in Title 21 of the U.S. Code of Federal Regulations (21 CFR). Materials used for the filter media and hardware are suitable for food contact in accordance with EU 10/2011.
07 / 09
CAPSULE INTEGRITY
Minimum burst pressure: 123.5 psi (8.5 barg)
08 / 09
Integrity Test
| Pore size | Minimum bubble point | Wetting fluid |
|---|---|---|
| 0.2/0.2 µm | 55.1 psi (3.8 barg) | Water |
| 0.45/0.2 µm | 55.1 psi (3.8 barg) | Water |
| 0.8/0.45 µm | 39.2 psi (2.7 barg) | Water |
09 / 09
Product Configuration / Ordering Information
| Product number / model | Pore size | Length | Inlet | Outlet | Vent | Drain | Filling bell |
|---|---|---|---|---|---|---|---|
| P-PT72KASTCS | 00*1=0.1/0.04µm | H=1.5 inch | 1T=1" TC | 1T=1" TC | S=Stäubli | S=Stäubli | B=Filling bell |
| 00*2=0.2/0.04µm | S=2.5 inch | MT=0.5" TC | MT=0.5" TC | H=Hose barb | H=Hose barb | ||
| 0021=0.2/0.1µm | D=4 inch | M6H=3/8" multistep hose barb | 7H=1/2" hose barb | ||||
| 0022=0.2/0.2µm | L=5 inch | 8NF=1/2" NPT-F | |||||
| 0042=0.45/0.2µm | M6H=3/8" multiple hose barb | ||||||
| 0064=0.65/0.45µm | |||||||
| 0104=1.0/0.45µm | |||||||
| 0106=1.0/0.65µm | |||||||
| 0108=1.0/0.8µm |
